Equipment

Cnc 3

CNC Vertical Machining Center

Haas :

  • 1st VF-3APC Machining Center –  Pallet Changer & 3-D Machining
  • 2nd VF-3APC Machining Center – Pallet Changer, 4 Axis Capabilities & 3-D Machining
  • 3rd VF-4 Machining Center
  • All have Mastercam X9 CNC Programming Software
  • All have Spaceclaim CAD Software

Press Equipment

  • 500 Ton Minster, 108″ x 54″ Bed, Servo Feeder
  • 200 Ton Minster, Servo Feeder (12″Wide X .375″ thickness)
  • 200 Ton CMC Bliss, Servo Feeder
  • 150 Ton Verson
  • 150 Ton Niagara
  • 100 Ton Niagara
  •   60 Ton Minster 6
  •   60 Ton Niagara
  •   60 Ton Verson
  • Automatic Cutoff Press
  • 60 Niagara
  • 60 Verson
  • 500 Minster
  • minster 6 small
  • 150a small
  • minster small
  • verson small
  • IMG_20210603_141228
  • IMG_20210603_141237

Quality Inspection

  • Starret RGDC DCC 28 X 28 X 24 CMM with Renshaw PH10A probe
  • Brown & Sharpe O.N.E. 775 Coordinate Measuring Machine (CMM) Dimensions (MM)
  • Fully Equipped SPC Computerized Inspection Stations, with real time recording
  • MicroVu Optical Comparator – 10X, 20X and 30X magnification
  • Computerized Gauge Calibration System
  • Instrom Hardness Tester

Robotic Mig Welding

  • Fanuc Arc Mate 100iB/3L Six Axis Robotic Welder – Qty 2
  • All Fixture with Automatic Clamp for Dimensional Control
  • Acid Etch Weld Inspection
  • Robo Weld Small
  • Lincoln fanuc robotic welder 3
  • migwelding
projectionwelding

Resistance / Projection Welding

  • 20 Kva Federal Resistance Welders – Qty 3
  • 50 Kva National Resistance Welders – Qty 4, equipped with Entron Weld Controllers and Pod displacement sensors. Real time monitoring and recording per every weld.

New Vista Vertical Thread Checking Machine

  • New Vista Mechanical Thread Checking with Automatic Part Approval System
  • Approves threads at 17 inch/ounces of torque
  • New Vista 3-Spindle Thread Verification System
New Vista 2
  • toolingequipment
  • Manual Surface Grinder - Zedco Maybe

Tooling Equipment

  • Bridgeport Machines – Qty 2
  • Lathes – Qty 2
  • Surface Grinders – Qty 2
  • Drill Presses – Qty 2
  • Heat Treating Oven
  • Tree CNC Center for Thread Milling
  • Minor tool repairs done in-house
  • Solid working relationship with tooling facilities

Tumbling & Rust Proofing

  • Tumbling & Rust Proofing Automated Fanuc Robot Tumble & Rust Proofing System
  • 30-Day Shelf Life
  • Barrel Tumbler
  • processing2
  • Beamer Laser Engraving

Miscellaneous Processing Equipment

  • Pemsetter Series 4 Pem Nut Machine
  • Emhert Riveting System – Qty 2
  • Large Assembly Area
  • Horizontal Milling Machines – Qty 2
  • Soco Automated Saw Cutoff
  • Tiger Automated Saw Cutoff
  • Shaft Chamfering Machines – Qty 3
  • Beamer Laser Marking System

Material Finishing

  • Zinc Plating Line – Current Salt Spray
    • Spec:
      • Plating:
        • General Motors:  GM4345M 3U24/0
        • Delphi/Nexteer:  33001800 Grade 07 (600 Hrs of No Red or White Rust)
  • Aluminum Spray Wash
    • Meets / Exceeds Nexteer Cleanliness requirement for particulate size and total weight.
  • E-Coating (Outsourced)
    • Spec:
      • Plating
        • General Motors:  GM4350M Class A336
  • Washline
